| Technical Datas | |||
|---|---|---|---|
|
T = TERRA-HAMMER with fused on earth displacement head TU = TERRA-HAMMER with interchangeable head adapters TR = TERRA-RAM, for steel pipe ramming and pipe bursting (berstlining) S = TERRA-HAMMER Version S, with quick reverse (1/4 turn of the air hose) F = TERRA-HAMMER Version F, with remote control reverse S/F = TERRA-HAMMER, available in Version S and Version F K = TERRA-HAMMER Version K, not glued, can be serviced without heating SK = TERRA-HAMMER Version S + Version K KOK-LD = TERRA-HAMMER with traceable KOK-LD adapter TERRA AG se reserva el derecho de cambios técnicos en cualquier momento. |
|||
| Diámetro |
360 mm
|
14"
|
|
| Tubo de acero |
200 - 1'000 mm
|
8" - 40"
|
|
| Largo |
1.75 m
|
69"
|
|
| Peso |
663 kg
|
1.460
|
|
| Fuerza de impacto |
840 to
|
925 US tons
|
|
| Frecuencia |
280 /min
|
280 /min
|
|
| Consumo de aire |
12 m3/min
|
1.200
|
|
| Impresión |
6 - 7 bar
|
85 - 100 psi
|
|
