| Datos técnicos | |||
|---|---|---|---|
|
T = TERRA-HAMMER with fused on earth displacement head TU = TERRA-HAMMER with interchangeable head adapters TR = TERRA-RAM, for steel pipe ramming and pipe bursting (berstlining) S = TERRA-HAMMER Version S, with quick reverse (1/4 turn of the air hose) F = TERRA-HAMMER Version F, with remote control reverse S/F = TERRA-HAMMER, available in Version S and Version F K = TERRA-HAMMER Version K, not glued, can be serviced without heating SK = TERRA-HAMMER Version S + Version K KOK-LD = TERRA-HAMMER with traceable KOK-LD adapter TERRA AG se reserva el derecho de cambios técnicos en cualquier momento. |
|||
| Diámetro |
200 mm
|
8"
|
|
| Tubo de acero |
150 - 400 mm
|
6" - 16"
|
|
| Largo |
0.9 m
|
35
|
|
| Peso |
112 kg
|
245 lbs
|
|
| Fuerza de impacto |
155 to
|
170 US tons
|
|
| Frecuencia |
550 /min
|
550 /min
|
|
| Consumo de aire |
4 m3/min
|
141 cfm
|
|
| Impresión |
6 - 7 bar
|
85 - 100 psi
|
|
